Warning: Make sure the router bit is properly fastened and tightened in the router’s collet and the bit can rotate freely without any obstructions.
Instructions: Slowly dial up the RPMs on your router to the recommended maximum. Then, dial back if needed to find the “sweet spot”. The sweet spot is the speed at which the least resonant vibration is present. If the sweet spot cannot be achieved within 5,000 RPMs of the max, check the collet for residue or other debris and start over.
Download Router Bit RPM Chart
|
Bit Diameter (Inches)
|
Max RPM
|
Min RPM
|
|---|---|---|
|
1
|
24,000
|
19,000
|
|
1.1
|
24,000
|
19,000
|
|
1.2
|
24,000
|
19,000
|
|
1.3
|
24,000
|
19,000
|
|
1.4
|
24,000
|
19,000
|
|
1.5
|
24,000
|
19,000
|
|
1.6
|
22,500
|
17,500
|
|
1.7
|
21,100
|
16,100
|
|
1.8
|
20,000
|
15,000
|
|
1.9
|
18,900
|
13,900
|
|
2
|
18,000
|
13,000
|
|
2.1
|
17,100
|
12,100
|
|
2.2
|
16,300
|
11,300
|
|
2.3
|
15,600
|
10,600
|
|
2.4
|
15,000
|
10,000
|
|
2.5
|
14,400
|
9,400
|
|
2.6
|
13,800
|
8,800
|
|
2.7
|
13,300
|
8,300
|
|
2.8
|
12,800
|
7,800
|
|
2.9
|
12,400
|
7,400
|
|
3
|
12,000
|
7,000
|
|
3.1
|
11,600
|
6,600
|
|
3.2
|
11,200
|
6,200
|
|
3.3
|
10,900
|
5,900
|
|
3.4
|
10,500
|
5,500
|
|
3.5
|
10,200
|
5,200
|
Edge Banding Router Bit Set V-Design Tongue & Groove - 1/2" Shank - Yonico 15225
Add a solid wood edge to the ends of your plywood or MDF shelving for a neat, finished look. Can also be used in the place of conventional tongue & groove joints where a perfect fit is necessary. The 90 degree design provides for easy and precise set up. Use with up to 1" stock. Two flute carbide cutters & 1/2" shanks.
Architectural Molding Router Bit - 16133
Add dramatic moldings to furniture or make crown moldings, base, case and chair rails all with this one bit. Two flute carbide cutters with ball bearing guides. 1/2" shank.
Architectural Molding Router Bit - 16140
Great for cabinet frames, raised panel doors, counter tops, crown moldings and trim. Ideal accents for bookcases, small furniture pieces, table tip undersides, interior trim and even large picture frames. Can also be purchased as part of a 10 piece molding set (item #16101) Two flute carbide cutters and 1/2" shank.
Triple Bead/ Column Molding Router Bit - 16159
Create triple bead column and face moldings to add a beautiful finished look to a wide range of projects. Two flute carbide cutters with ball bearing guide. 1/2" shank.
Bit Specs
